Eaton 1000587568 LCA Position Sensor | Endurant HD OEM
Eaton 1000587568 LCA Position Sensor (Linear Clutch Actuator Position Sensor) for Endurant HD transmissions. Hall-effect sensor reads magnet on LCA (A-10004457). Fixes Fault Code 250. Direct OEM replacement for EEO-17F112C & EEO-18F112C. Global shipping & lifetime warranty. Get your quote today!
Product Details
Eaton 1000587568 LCA Position Sensor – Endurant HD OEM
Factory-direct OEM replacement part for Eaton Cummins Endurant HD automated transmissions. The 1000587568 is the official Linear Clutch Actuator (LCA) Position Sensor (Hall-effect type). It reads the magnet on the LCA to precisely monitor clutch position and sends real-time data to the Transmission Control Module (TCM). Essential for smooth automated shifting and clutch control in high-mileage heavy-duty applications.
Why Choose the Eaton 1000587568 LCA Position Sensor?
- Hall-effect sensor – accurate clutch position feedback for the LCA
- Direct OEM replacement for Fault Code 250 issues
- Works with High Preload LCA (A-10004457) and all Endurant HD MTMs
- Plug-and-play installation with proper calibration
- Restores full automated transmission performance
- 28 years of OEM-level manufacturing experience at Volgen Power
Technical Specifications
| Parameter | Specification |
|---|---|
| OEM Part Number | 1000587568 |
| Sensor Type | Hall-effect LCA Position Sensor |
| Function | Reads the magnet on the Linear Clutch Actuator to determine the clutch position |
| Connector | Integrated into 74-Way Transmission Harness |
| Resistance Range (key off) | 7.5k–22k Ohms |
| Reference Voltage | 4.75–5.25V (key on) |
Vehicle & Transmission Compatibility
Designed exclusively for Eaton Endurant HD Series:
| Transmission Models | Application Notes |
|---|---|
| EEO-17F112C / EEO-17F112C-XD | 17-speed Endurant HD |
| EEO-18F112C | 18-speed Endurant HD |
Popular Applications: Freightliner Cascadia, Peterbilt 579/567, Kenworth T680, International LT – paired with Cummins X15 engines.
Important Note: This 1000587568 LCA Position Sensor is the direct OEM replacement for Fault Code 250 conditions (sensor signal issues, magnet not detected, out-of-range position, etc.). It pairs with the High Preload Linear Clutch Actuator (A-10004457).
Installation Highlights
Requires MTM access. Disconnect the 74-Way harness, remove the MTM if necessary, replace the integrated sensor assembly, and perform full clutch calibration using ServiceRanger. Torque all fasteners to specification. Total service time: approximately 3–4 hours (transmission removal may be required depending on the vehicle). Always reference Eaton Endurant HD Service Manual TRSM0950.
Why Buy from Volgen Power?
- 100% genuine OEM specification – direct from the Eaton supply chain
- Factory direct pricing – up to 40% lower than dealerships
- Lifetime warranty on all transmission components
- Fast global shipping from China + USA warehouse stock
- Trusted by fleets in 70+ countries since 1996
- Full technical support & ServiceRanger calibration guidance
Frequently Asked Questions
What does the Eaton 1000587568 LCA Position Sensor do?
It is a Hall-effect sensor that reads the magnet on the Linear Clutch Actuator (LCA) to tell the TCM exactly where the clutch is positioned (engaged or disengaged).
Is this the same as the sensor in the MTM?
Yes – the LCA Position Sensor is integrated into the Mechatronic Transmission Module (MTM). Replacing it typically requires MTM service or full MTM replacement.
Does this fix Fault Code 250?
Yes – Fault Code 250 (LCA Position Sensor) is the exact code triggered by this sensor. Replacing the 1000587568 resolves FMI 0-9, 12-18, 20, 31 issues in most cases.
Is it compatible with the High Preload LCA (A-10004457)?
Yes – it works with both original and High Preload LCAs (A-10004457 / A-10004457R).
What is your warranty on this part?
Lifetime warranty against manufacturing defects when installed correctly and calibrated per factory procedure.
